Automatic Irrigation using Centre Pivot Irrigation System

Abstract

In most of the agriculture lands the crops are over watered without checking the soil dampness. This leads to the waste of water resource which can be utilized in some other areas where there is in need of water. The project presents the use of correct soil moisture sensors which helps to ease out the pain to monitor and keep records about the changes in soil moisture. Using the Arduino Uno R3 micro controller with, moisture sensor and temperature sensor, temperature are measured and analyzed. The soil moisture sensor for a certain duration, provides information related to the moisture status of the soil. The Arduino Uno will collect and process the data received from the Sensors. When a threshold moisture level of the soil is reached, the water will supply accordingly. This is essential because water must be provided to the plant at a particular time for a good yield. The primary motivation behind the ventures to keep up soil dampness level so that there is no damage to the harvests. Soil dampness sensors fundamentally utilized for estimating the gauge volumetric water content. We are using center pivot irrigation system for application of our project. This project is highly useful for farmers, Nursery professionals for eradicating traditional or Manual method of irrigation system.

Introduction

I. INTRODUCTION

Smart irrigation control technology has continuously evolved over the last 15 years. For modern agriculture, a smart irrigation system is one of the best techniques that gives more production in minimum duration. Smart irrigation is fully automated and minimizes manual handling in agriculture. In this we are using Center Pivot irrigation system to irrigate the filed. This spray irrigation is a modern and commonly-used system of irrigating, but it also requires machinery. This system is similar to the way you might water your lawn at home stand there with a hose and spray the water out in all directions. Large scale spray irrigation systems are in use on large farms today. On the Center Pivot system, we require Electric motors to move each frame in a big circle around the field (the tube is fixed at the water source at the center of the circle), squirting water. To execute the project, we have Soil moisture sensor inserted in soil, and which is part of embedded system. Here the soil moisture sensor gives reading of soil moisture on present time of the field and if moisture in soil is decreased to certain level, motor will turn on immediately. And after required amount of water is gained by the field the motor will turn off automatically.

  A. Objectives of Project

 To understand the basic principle of project

1. Development of the working model of project.
2. To spread the awareness of technology.
3. Use Arduino IDE for coding in Arduino device and various dependencies.
4. Proper research for Arduino device and its circuit.
5. Proper circuit design for the project.
6. Proper testing and debugging of the device configuration.

B. Aim of project

To allow the surveillance of the crops so as to not occur losses. Also maximizing irrigation efficiency and reducing water waste, while maintaining plant health and quality. To improve the utilization of water in irrigation systems.

C. Project Details

Where our project innovation will use? Our project is typically based on Indian farmers. Their efforts and dedication towards their works are not responding to their results, due to change in climatic conditions and irregularities in water supply. So, In order to change this system our project will be much needful for the farmers as well as farming systems.

II. WORKING PRINCIPLE

As we are using a soil moisture sensor that,

1. Senses the moisture content in the soil.
2. Send this data to the Arduino that we are using.
3. Soil moisture sensors can send data in both. in analog as well as in digital.
4. So, we are using the analog data here to get the accuracy in the project.
5. We insert the soil moisture sensor in the soil and connect it to the Arduino and the sensor sends the data to the Arduino about the moisture inside the soil.
6. It makes the smart irrigation controller. the Arduino will get the action on the data.  According to the condition given in the program, if the soil moisture sensor detects no moisture or very little moisture then the pump will get started and the Center Pivot irrigation system will come in action and it will water the plants. After the field got sufficient amount of water, then the pump will automatically turn off. And the Center Pivot Irrigation system will also get stop.

References

Dynamic Modeling of Crop–Soil Systems to Design Monitoring” by Jorge Lopez-Jimenez, Alain Vande Wouwer, Nicanor Quijano, 2022. [2] “Challenges and opportunities in precision irrigation decision-support systems for center pivots” by Jingwen Zhang, Kaiyu Guan, Bin Peng, Chongya Jiang, Wang Zhou, Yi Yang, Ming Pan, Trenton E Franz, Derek M Heeren, Daran R Rudnick Published 29 April 2021. [3] ” Smart farm irrigation: Model predictive control for economic optimal irrigation in agriculture “by Gabriela Cáceres, Pablo Millán, Mario Pereira, David Lozano, 2021. [4] “Application of wireless sensor networks in the field of irrigation” by Loubna Hamami, Bouchaib Nassereddin, 2020. [5] “Irrigation of greenhouse crops” by Georgios Nikolaou, Damianos Neocleous, Nikolaos Katsoulas, Constantinos Kittas 2019. [6] “Assessment of economic returns by using a central pivot system to irrigate common beans during the rainfed season in Central Brazil” by Ludmilla Ferreira Justinoa, José Alves Júniora, Rafael Battistia, ?, Alexandre Bryan Heinemannb, Caio Vinicius Leitec, Adão Wagner Pêgo Evangelistaa, Derblai Casaroli. Agricultural Water Management 224(2019). [7] “Wind drift and evaporation losses of a mechanical lateral-move irrigation system: Oscillating plate versus fixed spray plate sprinklers” by Emanuele Baifus Mankea, Bernardo Gomes Nörenbergb, Lessandro Coll Fariac, José Maria Tarjuelod, Alberto Colomboe, Maria Clotilde Carré Chagas Netaa, José Maria Barbat Parfitt. Agricultural Water Management 225 (2019). [8] SMART IRRIGATION SYSTEM USING iot*Meghana Gupta Arakere, Avik Seal and Tejomurthula Bhuvana Teja Asian Journal of Science and Technology Vol. 10, Issue, 06, pp.9756-9768, June, 2019. [9] Automation of irrigation system using iot, International Journal of Engineering and Manufacturing Science. ISSN 2249-3115 Volume 8, Number 1 (2018) pp. [10] “CENTER PIVOT IRRIGATION SYSTEM LOSSES AND EFFICIENCY” by Danny H. Rogers, Jonathan Aguilar, Isaya Kisekka, Freddie R. Lamm , Proceedings of the 29th Annual Central Plains Irrigation Conference, Burlington, Colorado, Feb. 21-22, 20173 [11] Smart Irrigation System using IOT Arif Gori1, Manglesh Singh2, Ojas Thanawala3, Anupam Vishwakarma4, Prof. Ashfaque Shaikh Student, Computer Engineering, Rizvi College of Engineering, Mumbai, India, Vol. 6, Issue 9, September 2017. [12] “Sensor-based model driven control strategy for precision irrigation” by Camilo Lozoya, Carlos Mendoza, Alberto Aguilar, Armando Román, Rodolfo Castelló , 2016 . [13] “Sensor based automated irrigation system with IOT” by Karan Kansara, Vishal Zaveri, Shreyans Shah, Sandip Delwadkar, Kaushal Jani 2015. [14] “Sprinkler Irrigation – An Asset in Water Scarce and Undulating Areas” by M. SHIVA SHANKAR, A.V. RAMANJANEYULU, T.L. NEELIMA AND ANUP DAS. Integrated Soil and Water Resource Management for Livelihood and Environmental Security. 2015. [15] “Field Evaluation of Center Pivot Sprinkler Irrigation Systems, Atbara Food Security Scheme” by Nezar A. Mostafa and Hassan E. Alsayim. Nile Journal for Agricultural Science (ISSN: 1585 – 5507) Issue 01, 2015. [16] “Deficit Irrigation Application Using Center Pivot Sprinkler Irrigation for Onion Production” by Arega Mulu and Tena Alamirew. International Journal of Basic and Applied Sciences Vol. 1 No. 2. 2012. [17] “Assessing suitability of modified center pivot irrigation systems in corn production , using low altitude aerial imaging techniques” by Momtanu Chakraborty, Lav R. Khot *, R. Troy Peters. [18] Rajkhowa, D.J., Das, Anup, Ngachan, S.V., Sikka, A.K. and Lyngdoh, M. (Eds.) pp 259-283. ICAR Research Complex for NEH Region, Umiam – 793103, Meghalaya, India. [19] Research on automatic irrigation control: State of the art and recent results R Romero, JL Muriel, I García, D Muñoz de la Peña Agricultural water management 114, 59-66, 2012 [20] “Analysis of water application uniformity from a centre pivot irrigator and its effect on sugar beet (Beta vulgaris L.) yield” by J.N. Ort?´z a, J.A. de Juan b, J.M. Tarjuelo. bio systems engineering 105(2010)367 – 379.3
