High Gain Modified Based on Switched Inductor

Abstract

The proposed work represents the Modified boost converter is able to regulate the output voltage and the choice of second inductor can give its current as positive and whereas for boost increases in the voltage will not able to regulate the output voltage. It has low semiconductor device voltage stress and switch usage factor is high. A power with 125 W is developed with a 20V input voltage and yields 222 V output voltage and the outcomes are approved through recreation utilizing MATLAB/SIMULINK/MODEL.

Introduction

I. INTRODUCTION

A modified boost converter is a type of DC-DC power converter that allows for voltage step-up and regulation. It is an improved version of the conventional boost converter, designed to provide better efficiency, reduced size, and improved performance.The boost converter is commonly used in various applications, such as renewable energy systems, battery charging, electric vehicles, and portable electronic devices. It works by converting a lower input voltage to a higher output voltage using an inductor, a diode, a capacitor, and a power switch (typically a transistor).The modified boost converter incorporates certain enhancements and additional control features to overcome some limitations of the conventional boost converter. Here are a few key features and improvements:

A. High Efficiency

The modified boost converter aims to achieve higher efficiency by minimizing power losses during the conversion process. This is achieved through the use of advanced-power semiconductor devices with lower conduction and switching losses.

B. Improved control Techniques

The modified boost converter employs advanced control techniques, such as pulse width modulation (PWM) and feedback loops, regulate the output voltage accurately. These control techniques help maintain a stable and constant output voltage despite variations in the input voltage and load conditions. Reduced size and weight: The modified boost converter often incorporates advanced components and designs that allow for a more compact and lightweight converter. This is particularly beneficial applications where space is limited or weight is a critical factor, such as in portable electronic devices or electric vehicles.

Conclusion

The Modified boost converter achieves high power conversion efficiency , minimizing power loss and enhancing overall system efficiency . This efficiency is essential for reducing energy consumption, improving performance ,and prolonging the lifespan of an electronic system.The quadratic boost converter DC-DC converter that efficiently steps up voltage levels using a quadratic relationship between the input and output voltages .It offers several advantages, including a wider voltage conversion range, high power conversion efficiency and simple circuit design. The Modified boost converter finds application in diverse fields such as renewable energy systems, electric vehicles ,and a high -power electronic devices.Its play a crucial role in stepping up the voltage generated by the renewable sources for grid intergration or battery charging.In electric vehicles ,it enables efficient power delivery and allows for the use of smaller and lighter components .Moreover, essential ,in high power electronic devices ,the quadratic boost converter is achieve the necessary high voltage level.By controlling switch and optimizing the energy transfer process, the quadratic boost converter achieves high power conversion efficiency,minimizing power loss and enhancing overall system efficiency. This efficiency is for reducing energy consumption ,improving performance , and prolonging the lifespan of electronic system . Furthermore, the simplicity of circuit design and control implementation in the quadratic boost converter facilities manufacturing process ,reduces cost and enhances reliability. In summary ,the quadratic boost converter is a valuable component in power electronics ,providing efficient voltage step -up capabilities , wide range conversion range ,high efficiency ,and simplicity in design . Its versatility and benefits make it a key player in various industries ,contributing to the development of a sustainable energy system and high -performance electronic devices.

References

[1] M. Forouzesh, Y. P. Siwakoti, S. A. Gorji, F. Blaabjerg and B. Lehman, \\\"Step-Up DC–DC Converters: A Comprehensive Review of Voltage Boosting Techniques, Topologies, and Applications,\\\" in IEEE Transactions on Power Electronics, vol. 32, no. 12, pp. 9143-9178, 06 March 2017. [2] Transactions on Industrial Electronics, Vol. 46, no. 7, pp. 2025-2034, Sep. 2010.Armani, Divya&Krishnasamy, VijayakumA. A. Fardoun, E. H. Ismail, \\\"Ultra step-up DC-DC converter with reduced switch stress,\\\" IEEE Tran&Gathering, R. (2016). “Non-isolated high gain DC-DC converter by quadratic boost converter and voltage multiplier cell”. Ainu Shams Engineering Journal. 10.1016/j.asej.2016.09.007. [3] A. Fardoun, E. H. Ismail, \\\"Ultra step-up DC-DC converter with reduced switch stress,\\\" IEEE Transactions on Industrial Electronics, Vol. 46, no. 7, pp. 2025-2034, Sep. 2010.Pranshu Agarwal, Sarajevo Kumar Singh” A Modular Magnetically Coupled Quadratic Boost Converter for Micro source Applications” in IEEE at 7th IET International Conference on Power Electronics, Machines and Drives (PEMD 2014) [4] M. S. Bhaskar, P. Sanjeevikumar, F. Blaabjerg, V. Fedák, M. Cernat and R. M. Karakul, \\\"Non-isolated and non-inverting Cock croft-Walton multiplier based hybrid 2Nx interleaved boost converter for renewable energy applications,\\\" Conf. Proc., IEEE Intl. Power Electronics and Motion Control Conf. (PEMC), Varna, pp. 146-151. 25-28 Sept. 2016 . [5] Pandav Kiran Maroti, P.Sanjeevikumar, Frede Blaabjerg, Viliam Fedák, Pierluigi Siano, Vigna K. Chandrasekhar, “A Novel Switched Inductor Configuration for Modified SEPIC DC-to-DC Converter for Renewable Energy Application”, Conf. Proc., 3rd IEEE Conf. on Energy Conversion, IEEE-CENCON\\\'17, Kuala Lumpur (Malaysia). [6] Pandav Kiran Maroti, M. S. Bhaskar, P. Sanjeevikumar, Frede Blaabjerg, Viliam Fedák, “A High Gain Modified SEPIC DC-to-DC Boost Converter Renewable Energy Application” Conf. Proc., 3rd IEEE Conference on Energy Conversion, IEEE-CENCON\\\'17, Kuala Lumpur (Malaysia), 10/2017. [7] Priya P, Basha SG, Niranjan VSV, Seyezhai R. Investigation of the MOSFET based Quadratic Boost Converter for Photovoltaic Applications. IJPERA. 2016 Oct; 1(3):26–9. [8] Dhanasekaran R, Arun Prasath T. Performance comparison of solar power using Quadratic Boost Converter with coupled inductor. International Conference on Advanced Communication Control and Computing Technologies (ICACCCT); 2014 May. p. 376–8. [9] R. J.Wai and R. Y. Duan, \\\"High step-up converter with coupled inductor,\\\" IEEE Trans. Power Electron., vol. 20, no. 5, pp. 10251035, Sep. 2005. [10] Gu B, Dominic J, Lai JS, Zhao Z, Liu C. High boost ratio hybrid transformer DC-DC converter for photovoltaic module applications. IEEE Trans Power Electron 2013;28(4):2048–58.

Copyright

Copyright © 2023 Akshaya Meera. G, D. Ashokararaju. This is an open access article distributed under the Creative Commons Attribution License, which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited.
