Need Based Design and Topology of Power Supply for Industrial Instruments

Abstract

Process control instruments plays decisive role in regulation and monitoring like control actions which requires efficient circuit analysis and different input and output power supplies to make it connectable in panels or used separately. This paper gives a comprehensive study of power supply used in instruments, based on power electronics principle used to improve circuit performance. Furthermore, it also includes analysis for energy conversion, switching devices, control methods, conduction modes and protection mechanism to make the supply efficient. Supply topologies i.e., Linear& Switched Mode Power supply are used as per the requirement of instruments. Both the supplies include different challenges and solutions to overcome losses and make the supply efficient. The analysis includes various parameters like voltage, current, power loss, waveform, efficiency, switching, feed-back and ringing. These parameters affect the whole supply if problem occurs in any of them.

Introduction

I. INTRODUCTION

Process control equipment in industries plays a critical role in monitoring and controlling a variety of industrial processes like indication of process and requires efficient circuit analysis for proper operation and reliable power solutions to make it efficient [1], [3]. This research paper includes comprehensive research focused on the power supply used in these devices, using power electronics principles to analysis and improve circuit performance. Equipment often uses different power topologies to meet specific needs such as Linear and switching power supplies [4], [16].

Each of these types of supplies presents unique challenges and requires customized solutions to minimize losses and maximize efficiency. Efficient energy conversion, reliable switching devices, effective control methods, and robust protection mechanisms are the key aspects in this work. The use of power electronics principles improves the performance and efficiency of power systems and ensures the stable and accurate operation of control [2], [7]. Power system analysis includes various parameters such as voltage, current, power consumption, waveform characteristics, efficiency, switching behaviour, feedback mechanism, and mitigation of ringing effects.

Problems with these parameters can have a significant impact on the overall performance and reliability of the power system. The bits of knowledge and strategies displayed in this paper will helps development of control supply innovation for mechanical hardware, driving to move forward execution, precision and effectiveness over an assortment of industrial divisions.

II. TYPES OF POWER SUPPLY

Industrial instruments mainly required DC to operate which can be achieved by rectification process of AC in which AC is converted to required DC to supply the circuit [5], [14].

Power supply can be achieved in various ways like transformer less power supply, linear power supply, switched mode power supply but every power supply has some restriction and advantages [8]-[13].

In case of transformer-less power supply we can get required DC output but has current limitation and energy loss which is not acceptable at high power requirement [6], [15].

In industry other two types of power supply which can be modified easily to make more efficient and required less maintenance. Power supply used in any instrument are of two types are selected as per requirement and application as below:

1. Linear power supply.
2. Switched mode power supply.

In both the power supply, basic difference comes in term of transformers, switching circuitry and input / output range of power supply.

Here, at first AC voltage is stepped down using linear transformer to get the desired stable output which is rectified using diode bridge and has a filter capacitor to make dc smooth from pulsating. Fig.1 shows the basic circuit of linear power supply which has input 230V AC in primary side and has two secondary outputs of 12V and 5V DC which is the basic need to drive 12V relays and 5V for display and led segments Fig.2. Linear power supply use transformer to step-down the high voltage input to required output, linear power supply use voltage regulator at output side connected with a filter providing the stable and constant output.

Linear power supply has simple working as it rectifies the AC input by stepping it down to DC, but has a disadvantage of using it at place where voltage fluctuates which interrupts the output in both low and high voltage situations. When input voltage become low which affects the transformer to generate less output as required which cause unstable in voltage regulator and output voltage become low. While in case of high voltage transformer generates high output and cause short-circuit in DC side by overloading the components, as transformer input fluctuate it cause secondary to raise to go down which affect the overall supply of circuit.

While taking Switched Mode Power Supply it gives advantages compare to linear power supply as under:

1. SMPS has higher efficiency as it uses MOSFET and transistor type switching device to control the power flow.
2. It is compact in size which makes it easy to use in limited space.
3. It is light in weight due to its compact size while linear supply is heavy compared to it.
4. As it worked on switching devices it provides wide input voltage range like 100V to 270V AC.
5. It provides wide output voltage range with multiple voltage levels
6. It delivers high efficiency,
7. It is cost effective.

V. PROTECTION CIRCUIT

Protection circuit in instruments are used in different ways to protect the switching devices, ICs and over all circuit from overloading or due to voltage spikes. Here, are the examples of circuit used in power supply are as below:

A. Fuse and MOV (Metal Oxide Varistor)

Using fuse and MOV before rectification or at input side to protect circuit from overload during load fluctuation. As load requirement changes and supply is designed to use at certain load conditions then it withdraw higher amount of current which may cause short-circuit. To avoid it, we use rated fuse which blow up after certain level of increment in current at load. Using MOV during change in voltage level helps to protect the circuit as the voltage spikes occurs for longer duration MOV become short-circuited which blows-up fuse.

B. Ringing effect and snubber circuit

Using snubber circuit across the switching device to solve hard switching issue during ON/OFF conditions of switch. Not using snubber circuit may cause ringing effect which is shown in Fig.7.

C. Types of Snubber circuit

By using the RC snubber circuit across the switch or switching device ringing must be solved easily which increases the efficiency and reduce stress across switch during ON/OFF time. In SMPS we widely used RCD snubber circuit to make it more efficient to supply flow that stored inside transformer through diode, RCD means resistor capacitor is connected in parallel connection and in series with diode across transformer’s primary side. Another option is placement of switching device to have air ventilation which makes it cool during fast switching operation as the it has auto shut down feature when input voltage suddenly arises to protect the switching device and whole circuit till supply become stable to use again. During high frequency switching SMPS makes humming sound and vibration which is due to hard switching of MOSFET or ICs which is resolved using snubber circuit.

Conclusion

In conclusion, this research paper includes the power supply that is widely used in industrial instruments to be connected with panels or to use separately. By using power electronics principles of rectifier, switching circuit, PWM generation, closed loop feedback and snubber protection to make the power supply more efficient, less power consumption, easy to use at certain voltage range, high performance and providing overload and short-circuit protection. In summation to this research, the ringing effect in switching devices create vibrations and humming sound that affects the life of switching devices by creating an undue stress on the instruments. In order to abate the ill effects of this phenomenon we deploy snubber circuit across switching device to ensure optimal working.
