Secure Image Sharing: Innovating Encryption and Concealment Methods

Abstract

Data security techniques, notably concealment of information in encrypted images, play a pivotal role in safeguarding digital assets. Nonetheless, many methods in this domain face challenges in effectively balancing security and embedding capacity. To tackle this issue, we propose a novel approach integrating hybrid coding and Chinese remainder theorem-based secret sharing (CRTSS). Our method employs hybrid coding for concealing data within images, ensuring a robust embedding capacity. Initially, an iterative encryption process encrypts blocks while preserving their spatial correlation. CRTSS is then utilized to distribute these encrypted blocks across multiple shares, ensuring robust security. Leveraging the high geographical correlation within each share, data embedding is performed using the hybrid coding technique, effectively increasing capacity. The proposed method allows for the restoration of the original image without loss, even if some shares are corrupted or missing, as long as enough uncorrupted shares are available. Experimental results indicate superior embedding capacity compared to state-of-the-art techniques, including those relying on secret sharing. We present four variations of the proposed model, comprising two coupled and two separable cases, leading to a high-capacity concealment approach. The efficacy of our approach is demonstrated through experimental validation.

Introduction

I. INTRODUCTION

The rapid expansion of cloud computing and storage has coincided with the advancement of information technology, particularly with the maturation of 5G communication and transmission. Owing to the benefits of cloud computing, an increasing number of users are storing their information on the cloud, particularly multimedia files like photos, audio snippets, and video files. Since user data is stored on distant or cloud servers or is transferred over public networks, it is not necessarily secure and dependable. As a result, both industry and academics now give considerable attention to the data privacy issue. Numerous strategies exist to safeguard data security, including hashing, data concealing, encryption, and secret sharing (SS). Digital images are important data manifestations that have a wide range of uses in fields like legal forensics, photography, medicine, and the military. One of the areas of research interest is visual data concealing for security protection.

The secret data and cover image are the two things that make up the image data concealment system, as is widely known. To create a stego-picture in an undetectable way, secret data is integrated into the cover image. The picture data hiding mechanism should take into account two circumstances. One is that the cover image is superfluous and the secret data is uniquely safeguarded. Another is that, for military and medical purposes, both the cover picture and the secret data are essential, and both need to be error-free on the decoder side. It is obvious that the latter is reversible data hiding (RDH) and the former is irreversible data hiding. Due to its reversibility, Data Encryption is becoming more and more popular. Data Encryption techniques to date have primarily relied on lossless compression, difference expansion (DE), histogram shifting (HS), and pixel error expansion (PEE). These Data Encryption methods seek to achieve a favorable trade-off between modification distortion and embedding capability.

(1) For Data Encryption, we suggest a hybrid coding. The suggested hybrid coding can surpass the payload restriction of a single coding and obtain a high payload since it combines the benefits of several coding methods.

(2) For data concealing, we create a block-based CRTSS with limitations and a new iterative image encryption. There is greater space for data embedding since repeated encryption can precisely retain spatial correlation. Multiple encrypted shares with good spatial correlations can be produced by the planned CRTSS. Preprocessing is not necessary, and it won't cause data growth.

(3) To create a new Data concealment technique, we take advantage of the suggested hybrid coding, the iterative picture encryption, and the block-based CRTSS with limitations. The suggested approach works better in terms of embedding rate than several cutting-edge Data Concealment techniques, according to experimental results.

The rest of this paper is organized as follows. Section II reviews the related work of popular Data Concealment methods. Section III presents the proposed hybrid coding for Encryption. Section IV illustrates the proposed Data concealment method with secret sharing and hybrid coding in detail. The experimental results are discussed in Section V. Finally, Section VI concludes this paper.

II. RELATED WORK

Numerous Data Concealment techniques have been developed by researchers to date. The current Data Concealment methods can be broadly categorized into four groups: reserving room before encryption (RRBE) [26], [27], [28], [29], [30], [31], [32], [33]; vacating room by encryption (VRBE) [34], [35], [36], [37], [39], [40], [41], [42]; and SS based methods [43], [44], [45], [46], [47], [48], [49]. Together, these four categories comprise the majority of the current Data Concealment methods.

A. VRAE Based Methods

The initial image, which is built on a VRAE framework, was immediately encrypted using conventional image encryption algorithms such stream cipher and the advanced encryption standard (AES) in the early Data Concealment approaches [20], [21], [22], [23], [24], and [25]. The encrypted image in [20] is split up into many chunks. To make room for one hidden bit, the three least significant bits (LSBs) of each block's half pixels are flipped. The original image is simultaneously recovered and secret bits are extracted at the receiver side by using the fluctuation function after the marked image has been directly decrypted. Since then, some advancements in data extraction accuracy have been realized [21], [22]. Since then, some advancements in data extraction accuracy have been realized [21], [22]. Data extraction is not possible in [20], [21], and [22] when the encryption key is not provided. More adaptably, Zhang [23] and Qian and Zhang [24] suggested separable techniques that involve compressing some LSB planes of the stream cipher encrypted image to make more space for data embedding. In this way, data extraction becomes independent of picture recovery and the encryption key. To achieve data concealment, some randomly selected pixels from the stream cipher encrypted image are changed with secret bits in [25] in place of their high bit-planes. Since there are two possible outcomes for a single high bit-plane, "0" and "1," the prediction errors produced by these two outcomes are compared in order to recover the original image.

B. RRBE Based Methods

Despite the stream cipher's strong performance in picture encryption, the loss of pixel spatial correlation makes it challenging to remove an embedding room directly from the encrypted image. Consequently, a few RRBE-based strategies were put forth to help achieve large payloads [26], [27], [28], [29], [30], [31], [32], and [33]. In order to free up space before picture encryption, Ma et al. [26] integrated a few LSBs of the texture area into the smooth area using the conventional RDH technique. Secret data is included in the released room. The patch-level sparse representation method is employed in [27] to significantly reduce the amount of space in the original image. A binary-block embedding (BBE) technique was suggested by A binary-block embedding (BBE) technique was proposed by Yi and Zhou [28]. BBE is used to embed the original image's lower bit-planes into its upper bit-planes, freeing up the lower bit-planes for data hiding. The most important bits (MSBs) were rearranged by Chen and Chang [29] to construct bitstreams, which were then effectively compressed to provide the embedding room. In [30], the same high bit-planes that are successively labeled are compared between the original pixel and its predicted value. Secret bits are stored on the bit-planes with labels. In [31], secret bits are embedded into the embeddable bit-planes in accordance with the labels generated by hierarchically dividing the prediction errors into three magnitudes. In Yin et al. [32], To obtain a high embedding capacity, Yin et al. [32] employed pixel prediction and compressed the high bit-planes of prediction errors. In order to evacuate the huge room prior to encryption, an adaptive L predictor for preprocessing is constructed in Mohammadi's [33] general RRBE framework for Data Concealment.

C. VRBE Based Methods

Although RRBE-based techniques provide outstanding embedding performance, their practical applicability may be limited because the content owner lacks the computational capacity to undertake pretreatment operations or is unaware that the following data is hidden. Some particular encryption-based techniques, especially VRBE-based techniques, were presented to overcome this problem. The encrypted image in [34], [35], and [36] is produced by block permutation and block-based bit-XOR, both of which are capable of maintaining the correlation inside each encrypted block. Next, data concealing is accomplished by using difference compression [36], adaptive block encoding [35], and difference histogram shifting (DHS) [34]. The original image is encrypted in [37] and [38] by using block permutation and disordering bit planes, which transfers the redundant space from the original image to the encrypted image. To remove space for data concealment, high bit-plane portions of the encrypted image are compressed using efficient sparse coding. In order to maintain spatial correlations among image blocks, Yi and Zhou [39] first encrypted the original image using block permutation and block-based modulation. They then used parametric binary tree labeling (PBTL) to insert secret data into the encrypted image. In [40], redundancy is preserved in the encrypted image by employing the CE technique, which encrypts the original image in chunks using the stream cipher.

Subsequently, the redundancy matrix format is employed to free up space for data embedding. In order to obtain high embedding capacity, Yu et al. [41] presented an adaptive difference recovery (ADR) based data hiding technique and subsequently implemented this technique in Data Concealment. A generalized methodology for high-capacity Data Concealment utilizing pixel prediction and entropy encoding was presented by Qiu et al. [42] and is applicable to both the RRBE and VRBE scenarios.

D. SS Based Methods

An original image is converted into an encrypted version and uploaded to the cloud using the Data Concealment techniques mentioned above. Attacks by a third party could compromise the encrypted image and result in incorrect image recovery on the recipient's end. Some secret sharing (SS) based Data Concealment techniques were proposed [43], [44], [45], [46], [47], [48], and [49] in an effort to increase the robustness of RDHEI. Wu et al. [43] used pairwise Shamir's SS [10] to encrypt the original image in order to create the encrypted shares, ensuring that each share's pixel pair difference is equal to that of the original pair. Secret data can be integrated into shares using the DE or DHS technique because of difference preservation. Another SS was proposed by Chen et al. [44]. Another SS-based Data Concealment technique was proposed by Chen et al. [44]. This method encrypts a pair of pixels using a degree 3 polynomial after preprocessing them using the DE technique. The encrypted pixel pair may contain one secret bit inserted in it. One data-hider does the data concealing in [43] and [44].

The original image might not be recovered in the case that the data hider is an attacker for the original image since it might be an unreliable third party. Some multiple data-hiders based Data Concealment approaches using SS were presented [45], [46], [47], [48], and [49] to address this problem. These methods distribute each share to a single data-hider and provide independent data hiding on each share. Two Data Concealment techniques via SS over Galois fields GF(p) and GF(28) were proposed by Qin et al. [45]. These two techniques allow the embedding room to be abandoned in each share by preserving the pixel disparities within the 2x2 blocks of each share after SS. Multiple data-hiders get the encrypted shares in [46], which are produced using a particular Shamir's SS [10]. Through the bit-plane substitution approach, each data hider incorporates secret data into their share. Because Shamir's SS is often built on a finite field Fp with prime size 251, it is not possible to communicate pixels with values larger than 251. Accordingly, in these Shamir's SS based algorithms [43], [44], [45], and [46], the pixels with values more than 251 are prepossessed. CRTSS [8] is used in [47] to encrypt the original image and produce several shares. The additive homomorphism of CRT and the DE method are used in each share to hide data. Pixel enlargement arises from the use of CRTSS [8] and needs to be solved by compressing two MSBs of each share using this method. Because the DE approach is used, this method's embedding capacity is not high, hovering around 0.5 bpp. First presented by Hua et al. [48], cipher-feedback secret sharing (CFSS) is a technique that can be used to share images. An approach called multi-MSB prediction is used to hide data. Using matrix theory, Hua et al. [49] originally presented a matrix-based secret sharing (MSS). To attain a high payload, they subsequently suggested an MSS-RDHEI approach utilizing block error mixture encoding (BEME).

In essence, these high-payload Data Concealment methods nearly take use of certain coding strategies to represent the image context with less information, freeing up space for secret data like BEME [49], PBTL [39], and entropy encoding [42]. These single-coding methods can yet be improved upon, even though they can yield a large payload. In order to introduce a novel Data Concealment approach, we suggest in this study a hybrid coding with a bigger payload.

III. METHODOLOGIES

A. Proposed Hybrid Coding for RDH

Here, we provide a hybrid coding scheme for data hiding. Entropy coding and hierarchical coding make up the hybrid coding method. Blocks are used to separate an image. Every block is encoded using either hierarchical or entropy coding. Additionally, the block is encoded using the coding technique that has more free space so that the embedding capacity is increased.

Assume that I is the original, 8-bit grayscale image with a size of H×W. First, the original image I is separated into n non-overlapping blocks, denoted by the numbers B1, B2,..., and Z, which are scanned in raster order. Every block has a t×t dimensions. The formula z=⌊H/t⌋×⌊W/t⌋ is evident. The prediction value of a block's pixel pi,j is determined as

Conclusion

Our innovative Data Concealment technique makes use of hybrid coding and secret sharing. A substantial embedding room for each encrypted share can be achieved by the suggested method\'s combination of block-based CRTSS and iterative encryption, which can effectively pervert correlations within the blocks. Hybrid coding is used in each encrypted exchange to hide data with a large payload. Furthermore, the suggested approach does not call either pre-processing or pixel extension. According to experimental findings, the suggested approach performs better in the payload than a few cutting-edge SS-based Data Concealment techniques. Future Work: Future research will look into how to use the suggested model in additional scenarios, including a combined Data Encryption in images. Expanding the concept of secret sharing to include other forms of multimedia, including audio and video, is also an intriguing avenue to pursue.
