Stabilization of Soil by Using Polypropylene Fibers

Abstract

This types of soil need to be stabilized in order to increase the shear strength of the soil, durability of the soil as well to prevent from the erosion. Various case studies have been carried out for these types of soil to increase the soil properties. In this case study raw fibre known as polypropylene fibre have been used to increase the soil properties and interlocking of the soil and has become the one of the major practices used in construction work. This paper purposes to conduct the case study to check the improvements in properties of sandy soil by adding raw material polypropylene fibre. Several lab tests have been carried out using varying percentage of reinforcement (0.05%,0.10%,0.15%,0.20% and 0.25%). The soil parameters like specific gravity, plastic limit, liquid limit, compaction test and direct shear test are studied. The results obtained, will strained towards the usability and effectiveness of the fibre reinforcement in the replacement of the deep foundation.

Introduction

I. INTRODUCTION

A. Polypropylene

Polypropylene (PP) is a thermoplastic polymer widely used in quilting, blend concrete and it is fluently available. In synthetic fiber polypropylene is the world’s alternate extensively product after polyethylene. Chemically, polypropylene filament is denoted as (C3H6).

Benefits of Polypropylene Fibers :-

1. Polypropylene (PP) is a low weight fiber.
2. It does not absorb water. It has good resistant towards water absorbtion.
3. Polypropylene has excellent chemical resistance. PP fibers are also good resistant to most acids and alkalis.
4. It has low thermal conductivity as compared to other fibers.

II. METHODOLOGY

In this research, laboratory experiments have been performed to search the use of polypropylene fibers to stabilize two types of soils. Various soil samples and polypropylene fiber mixtures were prepared in the laboratory and then examined for their engineering properties. The various tests like Proctor Compaction Test, CBR characteristics and the unconfined compressive strength of samples were investigated. This paper illustrates the findings from the laboratory experimenttions with particular emphasis on the use of above mentioned alternative materials that provide economic benefits as well as reduced environmental impacts comparatively. The various tests will have to perform to observe the engineering properties of soil.

A. Data Collection

Sample Collection:-

1. Sample no. 1: 12, Shiv colony, Londhe -414106 Type of soil :- Black cotton soil
2. Sample no. 2: 16, vajhari river, Daregaon -414106 Type of soil :-Alluvial Soil

Conclusion

1) On the basis of Direct shear test on soil sample no. 1, with fiber reinforcement of 5% there is a decrease in the cohesion of soil suddenly. After adding the fibers reinforcement of 15% & 25% there is an increase in the cohesion of soil sample from the cohesion value obtain in the shear test when 5% of reinforcement was added in a soil sample. But the final value of cohesion of soil after the addition of 25% of reinforcement is less than unreinforced soil sample. But when we adding the reinforcement in the soil in the proportion of 5%, 15%, 25% the value of the angle of internal friction increases from 24.41° to 43.22 °, 43.41°, 43.65° respectively. Therefore it should conclude that in given soil addition of PP fibers as reinforcement in given soil sample decreases the cohesion value of soil but meanwhile, it is increasing the value of an angle of internal friction marginally. So it should conclude that the use of PP fibers as soil stabilizer for given soil sample no. 1is not recommended. 2) The results of the UCS test for soil sample -1 are also similar that when we adding the reinforcement in the soil at the percentage of 5 %, 15 %, and 25 %, the UCS value of soil sample is an increase from 0.0562 Mpa to 0.0631 Mpa, 0.0639 Mpa and 0.0634 Mpa on a respective percentage of reinforcement which is not enough for future purposes for increases the strength of given soil sample. 3) The shear strength parameters for soil sample no. 2 - the given soil sample were had cohesion value equal to 0.35 kg/cm2. when we adding the fiber in soil in proportion of the 5%, 15%, 25% the value of cohesion is 0.49 kg/cm2, 0.504 kg/cm2, 0.54 kg/cm2 respectively. again the initial value of an angle of internal friction is 24.985°. after the addition of reinforcement 5%, 15%, and 25% the value of the angle of internal friction 25.26°, 29.94°, and 31.21° respectively. from the above results, it would conclude that the use of PP fibers as reinforcement is profitable and effective for soil sample no. 2. 4) On comparing the results from the UCS test of soil sample no. 2 the initial value of the UCS test corresponds to soil sample which is unreinforced soil was 0.0692 Mpa. after addition of reinforcement at 5%, 15%, 25% the value of the UCS test are 0.0938 Mpa, 0.0965 Mpa, 0.1037Mpa i.e. the UCS value increases at net percentage 49.8 %, which is good increment, therefore, it would conclude that PP fibers as reinforcement is good option for soil sample no. 2. 5) Overall it can be concluded that fiber reinforced soil can be considered to be good ground improvement technique specially in engineering projects on weak soils where it can act as a substitute to deep/raft foundations, reducing the cost as well as energy

References

[1] S Kumar P, Mehndiratta HC, Chandranarayana S, Singh SP (2005) Effect of randomly distributed fibres on flyash embankments. IE (I) J CV 86:113–118 [2] Maher MH, Gray DH (1990) Static response of sands reinforced with randomly distributed fibers. J Geotech Eng ASCE 116(11):1661–1677 [3] Marandi SM, Bagheripour MH, Rahgozar R, Zare H (2008) Strength and ductility of randomly distributed palm fibers reinforced silty-sand soils. Am J Appl Sci 5(3):209–220 [4] McGown A, Andrawes KZ, Al-Hasani MM (1978) Effect of inclusion properties on the behaviour of sand. Geotechnique 28(3):327–346. [5] Prabakar J, Sridhar RS (2002) Effect of random inclusion of sisal fiber on strength behaviour of soil. Constr Build Mater 16:123–131. [6] Ramesh HN, Manoj Krishna KV, Mamatha HV (2010) Compaction and strength behavior of lime-coir fiber treated black cotton soil. Geomech Eng 2(1):19–28 [7] Ranjan G, Vasan RM, Charan HD (1994a) Mechanism of fibre reinforced soil-a state of art. Indian Geotech J 24(3):241–262 [8] Ranjan G, Vasan RM, Charan HD (1994b) Randomly distributed discrete fiber reinforced silt. In: Proceedings of Indian Geotechnical. Conference, Warangal, India [9] Shukla SK, Sivaram N, Das BM (2009) Fundamental concepts of soil reinforcement—an overview. Int J Geotech Eng 3(3):329–342 [10] Wasti Y, Ozduzgun ZB (2001) Geomembrane–geotextile interface shear properties as determined by inclined board and direct shear box test. Geotext Geomembr 19(1):45–57 [11] Yetimoglu T, Salbas O (2003) A study on shear strength of sands reinforced with randomly distributed discrete fibers. Geotext Geomembr 21(2):103–110 [12] Zornberg JG (2002) Discrete framework for limit equilibrium analysis of reinforced soil. Geotechnique 52(8):593–604
